Cold planer

BM 2000/65 large planer: Simply revolutionary in the 2-metre class.


Leading the way in weight, efficiency and comfort.

BOMAG's BM 2000/65 large planer sets new standards in the 2-metre class - it is even lighter, more manoeuvrable, more cost-effective and particularly easy to operate. The cold planer's clever design offers the operator excellent all-round visibility. A clear view of the milling edge to the front enables extremely precise milling in the track. Its slim tail improves rear visibility and hence working safety. The BM 2000/65's sleek design results in a turning circle of only 1.7 m, making the planer highly manoeuvrable. Milling in tight bends or roundabouts is no problem with the BM 2000/65. When milling different road surfaces, asphalt and concrete selectively, operation is intuitive. BOMAG's operating concept focuses on short navigation steps and only a few submenus. And servicing the planer is made even easier by straightforward access to all maintenance points.

Share Page:
Emission stage Stage V / TIER4f
Weight 27.000 kg
Performance 470,0 kW
Request an offer Receive a non-binding offer

Find your nearest Dealer

Please enter your location

Searching for Spare parts?

Contact your distribution partner

Find your nearest dealer

Spare parts enquiries


Parts Catalogue for Light Equipment


Download to get Started

BOMAP is available for Android Smartphones und Tablets.

Download now!

Fields of application

Asphalt milling is a method for removing specified layers of asphalt road pavements.

1 / 1

BOMAG cold milling machines are designed for selective milling of lane and ground linings made up of a wide range of asphalt and concrete compounds. The different models are particularly suited for repairs or the complete removal of motorways and major federal roads, and for rural roads and inner-city work including work on roundabouts. With different working and milling depths, large areas can be removed quickly and completely in one work stage.


Our machines contain both power and performance. To deliver maximum productivity we invest heavily in perfecting our milling drums, holder systems and cutting tools.

On planers, the milling depth is set using hydraulic cylinders. When entering the cut, the machine operator is supported by an assistance system on BOMAG planers. The rear of the machine follows the front. The system regulates the height of the rear drives. This makes the operator's work easier.

Particularly important on the construction site and when milling: The machine operator must always have the decisive parameters in view and be able to intervene quickly at any time. All the important data is displayed clearly and easy to read on a 7" full-colour display. With the new generation of BOMAG planers, changing settings or selecting sensors is never more than three clicks away.

This adds more cutting tools. Due to the high density of the cutting tools, fine milling creates a very fine surface texture and a low thickness up to 40 mm / 1.57 inch. Fine milling drums are used to increase the skid resistance of smooth road surfaces which have been “polished” by traffic. They can at the same time remove light ruts and uneven areas. In addition, these drums can be used to prepare sites for laying thin layers, to remove road markings and for fine milling of floor surfaces inside buildings.

The BMS 15 L holder system is slimmer than other systems. The effect is a lower resistance which reduces fuel consumption and improves the advance travel rate.

By using the Ion Dust Shield, the fine particulate pollution produced during milling can be reduced by more than 80%. Unlike conventional dust extraction systems, the fine particulate matter is not simply extracted in the working area and blown out again on the conveyor belt, but bound by means of intelligent technology. This causes the fine particulate matter to clump permanently into coarse particles which can then be transported away with the milled material.

Cutting power per tool increases and pulverised material fragments are larger. Because of the reduced crushing effect in the milled material, energy is saved which can lead to a faster travel speed or lower fuel consumption. At the same time, the cutter has lower wear because the faster advance rate means the impact time of the cutting tools is reduced and they generate less heat. POWER DRUMS not only offer milling performance which is up to 30% higher than standard milling drums, they also provide lower wear and reduced fuel consumption. The line spacing of the cutters on the POWER DRUM is relatively wide and the surface structure created by milling is rough and coarse. POWER DRUMS are used to plane hard materials and for complete removal of asphalt pavements.

They can be used for multiple applications on a variety of milling jobs. The standard milling drum can be used for complete removal of whole road surfaces as well as for planing individual layers. The applications for standard planers extend from the removal of small sections of road (patches) to major surfacing work and road repairs, including milling duct trenches. The milled surface is an ideal base for laying new asphalt layers.

Call up the status of your vehicles from your computer or tablet. Full transparency at all times for your machine fleet with the new BOMAG TELEMATIC app for PC, iOS and Android devices.

Read more



  • Milling technology
  • Milling drum LA15 including wear protection on the sides
  • BOMAG BMS 15 L exchangeable toolholder
  • 3 Milling-Drum-speeds, 100, 112, 130
  • Proportional adjustable water injection, 0-12 l/min
  • Automatic water saving device
  • Levelling, 2 sides + slope
  • Wear-free, digital Milling depth display
  • Proportional Milling depth adjustment
  • Two proportional speeds for Milling depth-adjustment
  • Hydraulically operated side-plates with 500 mm (right) and 400 mm (left) stroke
  • Hydraulically operated front mouldboard
  • Hydraulically rear mouldboard with adjustable preload-pressure
  • Right side-plate for fast Drum-exchange
  • Automatic load-control
  • Automatic distribution of traction
  • Hydraulically foldable Conveyor with +65° swivel angle
  • BOMAG Dual Filtration
  • BOMAG Easy Cut
  • BOMAG Easy Level
    • Drive Systems
  • 4 crawler B1 size steerable, front or/and rear
  • Crab walk
  • Variable transport speed
  • Variable operating speed
  • Mechanical Drum-drive
    • Operation comfort
  • Fully vibration-isolated operator-platform
  • Comfort zones at the standing areas for fatigueless operation
  • Adjustable dashboards
  • Standardized self-explanatory, well-arranged dashboards
  • Large storage at ground level
  • Service- and maintenance-points ergonomic concentrated
  • Large Storage compartment at the operator platform including 24V plug and flexible layer
  • Diesel and AdBlue fill comfortable and safely place at the operator station
  • BOMAG Fast Select for a fast machine operation
    • Safety & environmental protection
  • Noise optimized design
  • Liquid cooled engine following latest emission rules ohne heißen Abgasstrahl nach hinten
  • Integrated working lights
  • Rotary-beacon
  • Mirrors
  • CE-conform safety-package with emergency- stop-switches
  • Back-up-alarm
    • Basic machine
  • Track chains B3 size


  • Storage compartment for cutting tools on the track chains
  • Weather protection roof
  • Plexiglas weather protection for the side railings
  • Water filling pump
  • High pressure cleaner
  • Hose reel
  • Dust reduction system
  • Auxiliary Drum Drive for easy tool exchange
  • Compressed air system
  • Additional motor for auxiliary function & emergency drive function
  • Additional compartment for cutting tool
  • Additional working-light, magnet base
  • Advanced lighting package – additional 142.000 lm
  • Ballast weights
  • Special colour
  • Biodegradable hydraulic oil
  • Slewable standing support
  • Vandalism protection
    • Milling technology
  • Quick-exchange drum-system
  • Milling-Drum 2000, BMS 15 L, LA15
  • Milling-Drum 2200, BMS 15 L, LA15
  • Milling-Drum 2000, BMS 15 L, LA8
  • Milling-Drum 2200, BMS 15 L, LA8
  • POWER DRUM 2000, BMS 15 L, LA23
  • POWER DRUM 2200, BBMS 15 L, LA23
  • Additional Milling Drum Bearing
    • Levelling Systems and electronic support
  • Additional external BOMAG Easy Level Display
  • 2 scanners left & right in front of the milling box

Further data on request / All data subject to change / Illustrations may contain optional features

You can find more information regarding the CO2 emissions of all machines here.

Maintenance with a concept

Maintenance, easy and fast.

Longevity and low maintenance are two essential design principles at BOMAG implemented in the smallest details, reducing service costs and non-productive time to a minimum. With BOMAG, all components for servicing are well positioned and freely accessible. This applies to tanks, service points in the engine compartment and work on the milling drum.

Extended warranties

Play it safe.

Peace of mind is priority number one: This not only applies to our machines. Protect yourself from unexpected costs even after expiry of the legal warranty. With our extended warranties, you receive all-round protection for up to 60 months.

Learn more

Original parts and service

Quality is the best protection for your investment.

When you see BOMAG on a machine, you can expect real quality. This applies both to our original parts and our service. Opting for a BOMAG means choosing top quality every time. Original parts and service are there to protect your investment. They ensure 100% machine power and availability – and ultimately the productivity and cost-effectiveness of your company. BOMAG offers a range of service products to keep you on the road.
